Technical Specifications
| Jumlah maksimal pengadukan per posisi pengaduk ( H2O) [l] | 100 |
| Motor rating input [W] | 186 |
| Motor rating output [W] | 136 |
| Motor principle | Brushless DC |
| Tampilan kecepatan | LCD |
| Minimal kecepatan [rpm] | 0/30 |
| Kecepatan maksimal [rpm] | 2000 |
| Maksimal viskositas [mPas] | 70000 |
| Keluaran maksimal dari batang pengaduk [W] | 136 |
| Permissible ON time [%] | 100 |
| Torsi maksimal batang pengaduk [Ncm] | 200 |
| Short-term - Torque max at stirring shaft at 30-600 rpm / up to 20 min [Ncm] | 200 |
| Maksimal Torsi pada batang pengaduk 600-1300 L/min [Ncm] | 120 - 100 |
| Maksimal Torsi pada batang pengaduk 1300-2000 L/min [Ncm] | 100 - 60 |
| Pengatur kecepatan | tidak bertahap/ otomatis |
| Pengaturan akurasi kecepatan [rpm] | ±1 |
| Deviasi pengukuran kecepatan n > 300 rpm [%] | ±1 |
| Deviasi pengukuran kecepatan n < 300 rpm [rpm] | ±3 |
| Stirring element fastening | batang penghubung |
| Diameter rentang chuck [mm] | 0.5 - 10 |
| Hollow shaft, inner diameter [mm] | 11 |
| Hollow shaft (push-through - when stopped) | ya |
| Fastening on stand | extension arm |
| Extension arm diameter [mm] | 16 |
| Extension arm length [mm] | 220 |
| Tampilan torsi | ya |
| Speed control | Elektronik |
| Nominal torsi [Nm] | 1 |
| Pengukuran torsi | tren |
| Deviasi pengukuran torsi [Ncm] | ±6 |
| Penunjuk waktu | Ya |
| Tampilan waktu | LCD |
| Rentang Pengaturan waktu [min] | 1 - 6000 |
| Material housing | ? |
| Kualitas kebersihan ruangan | Ya |
| Bunyi tanpa elemen [dB(A)] | 52 |
| ISO Cleanroom Class (900rpm) | Class 7 |
| ISO Cleanroom Class (1800rpm) | Class 8 |
| Dimensi (W x H x D) [mm] | 89 x 237 x 191 |
| Berat [kg] | 3.8 |
| Temperatur lingkungan yang dizinkan [°C] | 5 - 40 |
| Kelembapan relatif yang diizinkan [%] | 80 |
| Kelas proteksi sesuai dengan DIN EN 60529 | IP 54 |
| Sambungan | RS 232 Ya |
| Sambungan USB | USB-C |
| Daya/ voltage [V] | 100 - 240 |
| Frekuensi [Hz] | 50/60 |
| Input daya [W] | 186 |
